Automatic Key-way Milling Machine (PKM)
An automatic key-way milling machine specially designed for making key-ways on various workpieces. It is robustly design to give precise keyways at high production.The workpiece is clamped with self-centering vice. The table feed is automatic along with 0.1 mm / stroke depth of cut. At achieved desire final depth the machine gets automatically stopped with instant sound of buzzer.
- Automatic feed count
- Easily achieve P9 Tolerance
- Self-centering vice is used for holding the workpieces
- Ease length setting of performing Key-way operation
- Silent operation & smooth cutting
- Easy to operate for any lay-man person
- Easy operation compared to lathe machine or conventional milling machine
- Maintenance free machine
- Tablet Die-punch (Pharmaceutical) industry
- Gearbox, Submersible Pump & Electric Motor Manufacturers
- Textile, Printing & Packaging Machinery Manufacturers
- Engineering Job Works
- Machine Tool Industry
Specifications
PKM-1
PKM-2
PKM-3
Max. Spindle Speed :
2460 RPM
Upto 2460 RPM
Upto 2460 RPM
Table Feed :
0-600 mm / Min
0-600 mm / Min
0-600 mm / Min
Clamping Capacity :
15 mm - 70 mm
20 mm - 85 mm
25 mm - 95 mm
Max. Length of Key-Way :
Upto 150 mm
Upto 200 mm
Upto 200 mm
Key-Way Size :
3 mm - 12 mm
3 mm - 16 mm
3 mm - 20 mm
Depth of Cut :
0.1 mm/stroke
0.1 mm/stroke
0.1 mm/stroke
Control Type :
Semi-Automatic (Digital Counter Control)
Semi-Automatic (Digital Counter Control)
Semi-Automatic (Digital Counter Control)
Control Mechanism :
Mechanical - CAM with Rachet - Pawl
Mechanical - CAM with Rachet - Pawl
Mechanical - CAM with Rachet - Pawl
Spindle Operation :
Rack-Pinion Mechanism
Rack-Pinion Mechanism
Rack-Pinion Mechanism
Spindle Control :
Switch-gear Control
VFD with Variable POT
VFD with Variable POT
Table Control :
VFD with Variable POT
VFD with Variable POT
VFD with Variable POT
Standard Collet :
ER-20
ER-25
ER-32
Power Supply :
3-PH / 440VAC
3-PH / 440VAC
3-PH / 440VAC
